Desktop Soldering Machine

Desktop Soldering Machine, flexible and diverse soldering methods, with functions such as spot welding, drag welding (pull welding).
Temperature control type: Optional Wilo 200W, 150W, high power 600W and other temperature controls
Heater: 400W (high power) [optional Wilo 200W, 150W, high power 600W and other heating cores]
Wire supply method: 0.5-1.2mmm (With broken tin, other wire diameters can be customized)

GET A QUOTE


Product Description

Desktop Soldering Machine
Desktop Soldering Machine Details 5331R


Desktop Soldering Robot Features

Flexible and diverse soldering methods, with functions such as spot welding, drag welding (pull welding).
Aluminum profiles are molded and cast, no deformation, no rust, and stable operation.
Programming supports point-to-point, block-to-block copy arrays to reduce programming time.
Each motion axis adopts Lesai closed-loop motor to improve equipment reliability and lifespan.
Equipped with automatic cleaning function to improve product quality and soldering iron tip life.
The welding module has a buffer function to effectively reduce product damage.
Temperature range 150-480C, display real-time power consumption, PID algorithm and frequency conversion technology.
With tin breaking function, it can effectively reduce tin slag splash and improve product quality.
Supports the configuration of smoke purifier to solve the problem of solder smoke.
Supports the installation of preheating devices to solve soldering problems for large metal products.


Device Parameters


Project Parameter Four-axis soldering machine 331R Dual Y-axis single-head welding machine 5331R Double-head automatic switching soldering machine 5331D Double-head automatic switching soldering machine 5331R-2Q Three-way automatic soldering machine 5331R-35 Four-head automatic soldering machine 5331R-4
Itinerary
 (other itineraries can be customized)		 X-axis 300mm Repeat accuracy
±0.02mm		 500mm Repeat accuracy
±0.02mm		 500mm Repeat accuracy
±0.02mm		 500mm Repeat accuracy
±0.02mm		 500mm Repeat accuracy
±0.02mm		 500mm Repeat accuracy
±0.02mm
Y1-axis 300mm 300mm 300mm 300mm 300mm 300mm
Y2-axis / 300mm 300mm 300mm 300mm 300mm
Z-axis 100mm 100mm 100mm 100mm 100mm 100mm
R-axis 360° 360° 360° 360° 360° 360°
Load workload 5kg
XYZ 3kg
Drive mode Timing belt + guide rail (optional screw rod + guide rail)
Motor Form/Power 57 closed-loop motor (optional 400W same-service motor)
Drive Closed-loop drive (optional 400W simultaneous server drive)
Power supply AC 220V/50Hz
Rated power Max_350W
Driving power Voltage 24V DC
Electric current Max.3.5A/Axis
Temperature control type Optional Wilo 200W, 150W, high power 600W and other temperature controls
Heater 400W (high power) [optional Wilo 200W, 150W, high power 600W and other heating cores]
Wire supply method 0.5-1.2mmm (With broken tin, other wire diameters can be customized)
Machine dimension 620*600790mm 820*600*820mm 920*600*820mm 920*600*820mm 820*600*820mm 980*600*820mm
Machine weight 45Kg 65Kg 70kg 70kg 72kg 75kg


Desktop Soldering Machine Form


four-axis soldering machine Four-axis soldering machine
The four-axis automatic soldering machine adds a heating module rotation axis [R-axis] part on the basis of the three-axis automatic soldering machine.
It can basically achieve welding without dead corners and is suitable for spot welding and drag welding on the same plane, such as PCB, frequency converter, etc.
It can basically achieve welding without dead corners and is suitable for spot welding and drag welding on the same plane, such as PCB, frequency converter, etc.
Double Y single head soldering machine
The double Y-axis single-head automatic soldering machine adds a Y-axis and dual working platforms to the four-axis automatic soldering machine, which saves the time of replacing fixtures, avoids the situation of machines and others, and further improves product efficiency.
Double Y double head soldering machine Double Y double head soldering machine
The dual Y-axis double-head rotary soldering machine adds a welding module, dual working platforms, and dual heating modules to the dual Y-axis automatic soldering machine. It saves the time of replacing fixtures and at the same time double-head welding. In addition to the single-head equipment Basically, the efficiency is further improved.
Double head automatic switching soldering machine Double head automatic switching soldering machine
The double-head automatic switching soldering machine adopts automatic switching mode, which can realize products with different sizes of solder joints in one machine. Use a large soldering iron tip to solder larger spots, and use a small soldering tip to solder small spots. Automatic switching can better meet the customer's personality for the product's needs.
Can be equipped with 150W, 200W, 400W, 600W power soldering components
Three-way tin automatic soldering machine Three-way tin automatic soldering machine
The three-send automatic soldering machine can be used to solder three pins of the same component, which not only solves the problem of too small spacing.
Can be equipped with 150W, 200W, 400W, 600W power soldering components.
Four-head automatic soldering machine Four-head automatic soldering machine
The four-head automatic soldering machine can solder four points on the same product or the corresponding soldering points of the same four products at one time,which greatly improves the production efficiency of the product while ensuring quality.
Can be equipped with 150W, 200W, 400W, 600W power soldering components.
